Rally Kit E-Light FORCE – Husqvarna FE – Twalcom®

DESCRIPTION

“PROTECTED DESIGN by Akran Intellectual Property”

Racing Design and 4,750 lm.

The Rally Kit E-Light Force, equipped with a windscreen with adjustable inclination and a 9 LED headlight NOT approved RACE USE ONLY, is specifically designed and manufactured to provide greater aerodynamic protection, wider field of vision and enhanced safety in all low visibility situations. Installation is simple and quick thanks to the dedicated wiring. Simply disconnect the original connector from the stock fairing and insert the new connector. The lighting will be controlled directly by the stock light switch. No special equipment and/or specialized labor required. Everything can be installed in less than 40/45 minutes.

For our Rally Kit E-Light Force, we have chosen an approved DayLight that is compact and has very low consumption, combined with the new Vision-X LED headlight with 9 High Performance LEDs that is powerful, extremely robust, vibration-resistant and particularly suitable for Racing use. The power, depth and special light beam offer maximum visibility in all situations. All this with a consumption of only 45W. The special wiring included allows the DayLight alone to turn on and in the high beam position of the original light switch, the main headlight turns on. This energy saving makes it possible to install additional instrumentation (GPS, Roadbook, Rugged Tablet or other) without putting strain on the battery. The support frame is also prepared for a possible USB socket and offers ample space and protection for mounting a wide range of accessories.

All our Rally Kits can be completed according to different uses: Adventure, Raid and Rally Racing. For more information see the “Rally Kit Accessories” page.

DayLight technical specifications:

• Approval A02 R102 SM100 E09 16648
• A-0.3 /0.7 W.

LED Headlight Technical Specifications:

• NOT APPROVED – RACING USE ONLY
• Die-cast aluminum structure IP 68.
• 4,750 lm. – 45w. – 9-32V DC
• Width 40°
• Weight: 482 g.
• 24-month warranty.

Windscreen Specifications:

• Approval DOT 626 M5 32 AS7
• Height 360 mm.
• Adjustable inclination
• High thickness

Total Rally Kit weight: 1,580 g.

Available with black anodized frame and Transparent or Light Smoke Windscreen.

The package includes:

1. Anodized Peralluman support frame
2. New high-thickness windscreen with adjustable inclination (height 360 mm.)
3. Dedicated graphic frame, Yellow Fluo color
4. Approved DayLight A02 R102 SM100 E09 16648
5. 9 LED Headlight CE Certified
6. Two mounting/adjustment brackets
7. Dedicated “Made in Twalcom” plug and play wiring for direct connection to the original connector
8. Electrical installation materials
9. Installation instructions.
